Speedi Sleeves

Speedi Sleeves are used to repair worn running surfaces on the shaft. This is a quick and cost-effective alternative to repairing or replacing the worn shaft. An oil seal only seals properly if the running surface on the shaft is good. Thus, this surface should not be too smooth or too rough and should not be damaged and completely free of corrosion. A Speedi-Sleeve is a high-quality thin stainless steel bushing, which is pushed over the damaged part of the shaft.

Applications

Speedi Sleeves are placed on axles to repair the run-in or damaged tread. Repairing or replacing the axle is time-consuming and generally a costly exercise. In many cases, the Speedi Sleeve is a quick and cost-efficient alternative. The Speedi Sleeve can also be used as original equipment to avoid a costly machining operation on the axle surface.

Features and benefits:

Quick and easy installation
Cost-efficient replacement of run-in axle running surfaces
Minimum repair time required
Thin wall thickness eliminates the need for seal modification
Precision on the ground surface ensures long service life
Many options for standard dimensions

Surface roughness:

Ra = 0.2 - 0.8 μm
Rz = 1 - 5 μm
Rmax ≤ 6.3 μm

Surface hardness:

HV 220 (95 HRB)
Wear-resistant machining

Wall thickness:

Thin wall design

Installation

The Speedi Sleeve can be installed quickly and easily with the supplied mounting material. The mountingﬂens easily removable.

Instructions are included in the packaging:

Clean the run-in tread on the axle. Remove bumps with light sandpaper
Measure the diameter of tread at an unaffected location. Select the usable Speedi Sleeve based on this measurement
Place the supplied set against the edge of the sleeve
If the mounting sleeve is too small, a tube can also be used
Push gently in the middle of the mounting sleeve until the damaged area is reached
The sleeve should only be removed if it obstructs the application. If it must be removed, a notch should be made carefully before mounting to avoid damage
Mount the seal

The online store for all your seals

Speedi Sleeves can be ordered from Seal Supply easily and in several ways. You can place your order with us online, by phone or by e-mail. Creating your own webshop account gives you the necessary advantages. You will always have insight into stock and delivery times.

min.	max.	d1	D	b1	b	B	SKF	Seal Supply
			±1,6	±0,8	±0,8		partnumber	partnumber
11.99	12.07	12.0	15.5	6.0	8.4	47.63	99049	326354
12.65	12.75	12.7	15.5	6.3	8.7	50.8	99050	473654
13.89	14	14.0	19.1	6.3	9.9	46.51	99055	473655
14.22	14.38	14.3	19.1	6.3	9.9	46.51	99056	473656
14.96	15.06	15.0	19.1	5.0	9.0	47.29	99059	473657
15.82	15.93	15.9	19.1	8.0	10.3	50.8	99062	473658
15.9	16	16.0	18.2	8.0	11.1	50.8	99058	473659
16.94	17.04	17.0	22.2	8.0	11.0	50.8	99068	468582
17.32	17.42	17.4	22.7	8.0	11.1	50.8	99060	473660
17.88	18.01	17.9	24.4	8.0	11.1	46	99082	473661
19	19.1	19.1	24.0	8.0	11.1	50.8	99076	473662
19.28	19.33	19.3	23.8	8.0	11.1	50.8	99081	473663
19.81	19.91	19.8	23.8	8.0	11.1	50.8	99080	473664
19.94	20.04	20.0	23.6	8.0	11.0	50.8	99078	325287
20.62	20.7	20.7	30.2	9.5	14.3	76.2	99083	473665
21.77	21.87	21.8	29.3	6.3	9.5	50.8	99086	473666
21.87	22	22.0	30.2	6.6	9.1	47.14	99084	466068
21.87	22	22.0	30.2	8.0	12.0	46.02	99085	325839
22.17	22.28	22.2	27.8	8.0	11.1	50.8	99087	473667
23.06	23.16	23.1	30.9	8.0	11.1	46.91	99091	473668
23.88	24	24.0	28.7	8.0	11.1	50.8	99092	373610
24.54	24.64	24.6	28.7	8.0	11.1	50.8	99094	473669
24.54	24.64	24.6	28.7	15.9	18.3	50.8	99096	473670
24.94	25.04	25.0	33.0	8.0	11.0	50.8	99098	319085
25.88	26.01	26.0	33.4	8.0	12.0	46.05	99103	473671
26.92	27.03	27.0	33.5	8.0	11.1	46.81	99106	473672
27.61	27.71	27.7	35.7	8.0	11.1	15.88	99108	473673
27.94	28.04	28.0	34.9	9.5	12.7	46.81	99111	325840
28.52	28.63	28.6	38.1	8.0	11.1	17.48	99112	473674
28.52	28.63	28.6	38.1	9.5	12.7	17.48	99116	473675
29.31	29.41	29.4	34.3	9.5	12.7	17.48	99120	473676
29.79	29.92	29.9	35.6	8.0	11.1	17.48	99122	473677
29.95	30.07	30.0	35.6	8.0	11.0	17.48	99114	319078
30.1	30.23	30.2	35.6	8.0	11.1	17.48	99118	473678
30.89	31.04	31.0	39.7	8.0	11.0	15.88	99123	473679
31.42	31.57	31.5	39.1	8.0	11.1	17.48	99141	473680
31.67	31.83	31.8	38.1	8.0	11.1	17.48	99125	473681
31.93	32.08	32.0	38.1	8.0	11.1	17.48	99128	423742
32.94	33.05	33.0	40.5	15.0	18.0	25.4	99121	473682
33.27	33.43	33.4	40.5	12.7	15.9	20.65	99131	473684
33.22	33.38	33.4	40.6	6.3	9.5	20.65	99129	473683
33.86	34.01	34.0	41.3	12.7	15.9	20.65	99134	473685
34.82	34.98	34.9	41.6	8.0	11.1	20.65	99133	473686
34.82	34.98	34.9	41.6	12.7	15.9	20.65	99138	469785
34.93	35.08	34.9	41.6	13.0	16.0	20.65	99139	319080
35.84	35.99	36.0	45.2	13.0	17.0	24.99	99146	325841
36.45	36.6	36.5	45.2	9.5	12.7	25.81	99144	473688
36.37	36.53	36.5	45.2	14.3	17.5	25.81	99143	473687
37.85	38	38.0	45.2	13.0	17.0	24.99	99147	469794
38.02	38.18	38.1	45.2	9.5	12.7	25.81	99150	326039
38.02	38.18	38.1	45.2	14.3	17.5	25.81	99149	473689
38.61	38.76	38.7	47.2	11.1	14.3	25.81	99152	473690
39.34	39.5	39.4	47.2	11.1	14.3	25.81	99155	466151
39.6	39.75	39.7	47.2	14.3	17.5	25.81	99156	327193
39.78	39.93	39.9	47.2	15.9	19.1	25.81	99159	473691
39.85	40.01	40.0	46.9	9.9	12.9	25.4	99153	319993
39.93	40.08	40.1	47.0	13.0	16.0	25.98	99157	325850
40.69	40.84	40.8	49.2	12.7	16.3	25.4	99160	473692
40.84	41	41.0	49.2	12.7	15.9	25.81	99163	473693
41.2	41.35	41.3	47.6	8.0	11.1	25.81	99161	473694
41.2	41.35	41.3	47.6	14.3	17.5	20.65	99162	473695
41.83	42.01	41.9	53.0	11.3	14.5	21.49	99166	473696
41.83	42.01	41.9	53.0	14.3	17.5	21.01	99169	325851
41.99	42.14	42.1	53.0	14.0	17.5	21.01	99165	473697
42.8	42.95	42.9	48.4	8.0	11.1	22.23	99167	473698
42.77	42.93	42.9	48.4	14.3	17.5	22.23	99168	473699
42.85	43	43.0	48.4	12.7	15.9	21.44	99182	473700
43.56	43.71	43.7	51.6	14.3	17.5	20.65	99171	473701
44.09	44.25	44.2	52.4	9.5	12.7	20.65	99170	473702
44.37	44.53	44.5	52.2	9.5	12.7	20.65	99172	473703
44.37	44.53	44.5	52.4	13.5	15.9	22.3	99180	473706
44.37	44.53	44.5	52.4	14.3	17.5	20.65	99174	473704
44.37	44.53	44.5	52.4	19.1	22.2	20.65	99175	473705
44.73	44.88	44.9	52.4	14.3	17.5	20.65	99176	473707
44.93	45.09	45.0	53.0	14.0	17.0	20.62	99177	319082
45.16	45.31	45.2	54.0	16.9	20.3	26.97	99179	473708
45.95	46.1	46.1	53.1	14.3	17.5	25.4	99181	473709
47.17	47.32	47.2	54.8	14.3	17.5	25.4	99185	473710
47.4	47.55	47.5	55.6	22.6	26.0	25.4	99186	473711
47.55	47.7	47.6	56.0	4.5	7.5	18.9	99190	473715
47.55	47.7	47.6	56.0	7.5	10.5	18.9	99188	473714
47.55	47.7	47.6	56.0	9.5	13.1	26.67	99184	473712
47.55	47.7	47.6	56.0	14.3	17.5	25.4	99187	473713
47.93	48.08	48.0	56.0	14.0	17.0	24.99	99189	473716
48.49	48.64	48.6	56.4	9.5	12.7	25.4	99192	473717
49.12	49.28	49.2	56.4	14.3	17.5	25.4	99193	473718
49.12	49.28	50.0	57.0	14.0	17.0	24.99	99196	319081
50.22	50.37	50.3	58.8	14.3	17.9	26.67	99198	473719
50.72	50.88	50.8	61.1	14.3	17.5	25.4	99199	473720
50.72	50.88	50.8	61.1	22.2	25.4	25.4	99200	473721
52.25	52.4	52.4	62.7	19.8	23.8	34.93	99205	473723
53.92	54.05	54.0	61.5	12.7	19.1	32.54	99210	473724
53.95	54.1	54.0	61.5	19.8	23.8	34.93	99212	473725
54.91	55.07	55.0	62.0	20.0	23.0	31.75	99215	319084
55.52	55.68	55.6	63.5	19.8	23.8	33.35	99218	473726
55.52	55.68	56.0	64.3	19.8	23.8	80.01	99224	473727
55.83	56.01	56.0	64.3	12.7	15.9	33.35	99220	473728
56.57	56.72	56.6	64.3	12.7	15.9	33.35	99229	473729
56.57	56.72	56.6	64.3	19.8	23.0	31.75	99230	473730
56.82	56.97	56.9	65.1	19.4	22.9	31.75	99226	473731
57.12	57.28	57.2	64.3	8.0	11.1	33.35	99227	469793
57.12	57.28	57.2	64.3	19.8	23.8	33.35	99225	473732
57.91	58.06	58.0	66.0	19.8	23.8	34.93	99219	473733
58.65	58.8	58.8	68.3	19.8	23.8	34.93	99231	473734
59.11	59.26	59.1	69.8	19.1	22.2	38.1	99233	473735
59.92	60.07	60.0	70.7	9.4	11.4	37.36	99241	326789
59.92	60.07	60.0	70.7	20.0	23.0	34.93	99235	319083
60.3	60.45	60.3	69.8	13.4	17.4	34.93	99240	473738
60.25	60.4	60.3	69.8	15.1	19.1	34.93	99238	473737
60.25	60.4	60.3	69.8	19.8	23.8	34.93	99237	473736
61.82	62	61.9	71.8	19.8	23.8	35.38	99243	473740
61.85	62	61.9	71.8	12.7	15.9	36.2	99242	473739
61.9	62.05	62.0	71.8	12.7	15.9	36.2	99244	330641
63.22	63.37	63.3	73.0	19.8	23.8	35.38	99249	473741
63.42	63.58	63.5	71.6	14.1	16.5	22.61	99253	473744
63.42	63.58	63.5	71.6	19.8	23.8	34.93	99250	473743
63.5	63.65	63.5	71.8	12.7	16.7	35.38	99248	473742
63.75	63.91	63.9	71.8	19.8	23.0	36.53	99251	473745
64.92	65.07	65.0	72.4	20.0	23.0	34.93	99254	325170
65.02	65.18	65.1	73.4	19.8	23.8	34.93	99256	473746
65.91	66.07	66.0	76.0	19.8	23.8	31.75	99259	473747
66.5	66.65	66.6	77.4	19.8	23.8	34.93	99261	473748
66.6	66.75	66.7	77.4	12.7	15.9	34.93	99260	473749
66.57	66.73	66.7	77.4	19.8	23.0	34.93	99264	473751
66.68	66.83	66.7	77.4	19.8	23.8	34.93	99262	473750
67.82	68	68.0	79.4	19.1	22.2	42.88	99266	473752
69.27	69.42	69.3	79.4	19.8	23.0	33.35	99268	473753
69.6	69.75	69.7	77.8	19.8	23.8	31.75	99273	473754
69.77	69.93	69.9	78.1	36.5	41.3	41.28	99267	473755
69.85	70	69.9	79.4	10.3	14.3	31.75	99272	325852
69.72	69.88	69.9	79.4	19.8	23.8	31.75	99275	473756
69.72	69.88	69.9	79.4	28.6	31.8	33.32	99269	424226
69.93	70.08	70.0	79.4	20.0	24.0	31.75	99276	325842
71.35	71.5	71.5	81.0	15.1	17.5	31.75	99281	473757
71.83	72.01	72.0	81.9	19.1	22.2	34.11	99284	424022
72.09	72.24	72.1	81.9	12.7	16.7	31.75	99282	473758
72.8	72.95	72.9	81.0	19.8	23.8	31.75	99286	473759
72.97	73.13	73.0	81.8	19.8	23.8	31.75	99287	473760
74.6	74.75	74.6	84.9	12.7	16.3	33.81	99290	473761
74.6	74.75	74.6	84.9	19.8	23.8	33.35	99293	473762
74.93	75.08	75.0	83.1	15.1	17.5	27.51	99289	424277
74.93	75.08	75.0	84.0	22.0	26.0	33.35	99294	325843
75.49	75.59	75.5	82.2	20.6	25.4	31.75	99292	473763
75.49	75.59	76.0	85.1	20.6	25.4	32.54	99299	473766
75.95	76.1	76.0	85.3	12.3	15.9	33.81	99291	473764
75.95	76.1	76.0	85.3	14.3	17.5	34.93	99298	473765
76.2	76.35	76.2	82.2	20.6	25.4	32.54	99300	473768
76.12	76.28	76.2	82.3	20.6	23.8	34.93	99296	473767
76.4	76.56	76.5	85.2	12.7	15.9	50.8	99301	473770
77.83	78	78.0	88.0	19.1	22.2	52.22	99306	473771
79.25	79.4	79.4	89.7	17.5	20.6	50.8	99311	473773
79.25	79.4	79.4	89.7	20.6	25.4	50.8	99312	473774
79.81	80.01	79.9	89.9	19.1	22.5	34.93	99313	473775
79.91	80.09	80.0	90.0	11.0	15.0	34.93	99317	320294
79.91	80.09	80.0	90.0	21.0	24.0	34.93	99315	320489
81.92	82.07	82.0	91.1	16.8	21.5	44.45	99328	473776
82.55	82.7	82.6	90.8	15.1	18.3	34.93	99324	473778
82.55	82.7	82.6	91.1	17.5	22.2	31.75	99326	473780
82.55	82.7	82.6	91.1	20.6	25.4	34.93	99325	473779
82.47	82.63	82.6	91.3	20.6	25.4	34.93	99322	473777
84	84.15	84.1	93.7	20.6	25.4	34.93	99331	473781
84.76	85.01	84.9	94.0	17.0	21.0	35	99332	473782
84.76	85.01	84.9	94.0	21.0	25.0	35	99333	325853
84.79	85.01	85.0	90.9	10.1	12.7	36.35	99334	473783
85.67	85.83	85.7	93.7	9.5	12.7	35.81	99338	473785
85.67	85.83	85.7	93.8	20.6	25.4	34.93	99337	473784
87.25	87.4	87.3	97.6	19.8	23.0	35.71	99339	473786
88.32	88.47	88.4	97.4	19.8	23.0	35.71	99340	473787
88.9	89.05	88.9	97.2	8.0	12.7	34.21	99347	473789
88.82	88.98	88.9	97.6	15.9	20.6	34.21	99346	473788
88.82	88.98	88.9	97.6	20.6	25.4	34.21	99350	473790
88.93	89.08	89.0	97.6	15.9	20.6	34.24	99349	473791
89.92	90.07	90.0	101.6	11.1	13.7	46.05	99352	473792
89.92	90.07	90.0	101.6	13.4	16.9	44.45	99353	473793
89.92	90.07	90.0	101.6	18.0	23.0	46.05	99351	327553
89.92	90.07	90.0	101.6	23.0	28.0	44.45	99354	319079
90.42	90.58	90.5	99.1	20.5	25.4	44.45	99356	473794
90.42	90.58	92.1	102.4	20.6	25.4	44.45	99362	473796
91,90	92,05	91,97	102,39	20,65	25,4	44,45	99360	473795
92.02	92.18	92.1	102.2	12.7	15.9	44.45	99363	473797
93.6	93.75	93.7	102.2	20.6	23.8	45.72	99365	473798
93.57	93.73	93.7	102.4	8.0	11.1	22.23	99368	473799
93.57	93.73	94.7	102.2	19.8	23.0	45.72	99366	473801
94.67	94.82	94.7	102.4	11.9	15.1	45.72	99359	473800
94.92	95.07	95.0	102.2	21.0	24.0	45.72	99369	325844
95	95.15	95.0	102.4	8.7	12.7	45.72	99374	473802
95	95.15	95.0	102.5	11.9	15.1	45.72	99364	469831
95	95.15	95.3	102.1	17.5	22.2	45.72	99372	473805
95.25	95.4	95.3	102.2	8.7	12.7	45.72	99367	473804
95.15	95.3	95.3	102.2	14.3	17.5	45.72	99376	473803
98.25	98.4	98.3	106.3	20.7	25.4	47.63	99386	473806
98.37	98.53	98.4	107.2	20.6	25.4	47.63	99387	473807
99.95	100.1	100.0	109.5	20.6	25.4	52.07	99393	325845
101.55	101.75	101.6	111.1	12.7	15.9	52.48	99401	473810
101.55	101.75	101.6	111.1	15.2	18.4	52.07	99395	473808
101.55	101.75	101.6	111.1	16.5	19.7	34.93	99400	473809
101.55	101.75	101.6	111.1	20.6	25.4	52.07	99399	327383
103.89	104.09	104.0	112.7	20.0	24.0	35.99	99409	473811
104.7	104.9	104.8	113.5	20.6	25.4	34.93	99412	473812
104.9	105.11	105.0	113.5	20.0	23.2	35	99413	325846
106.25	106.45	106.4	114.3	20.6	25.4	34.93	99418	473813
107.34	107.54	107.5	117.1	19.8	23.0	36.53	99423	473814
107.9	108.1	108.0	117.1	20.6	25.4	36.53	99424	473815
109.91	110.11	109.9	125.0	12.9	16.5	31.75	99435	468562
109.78	110.01	110.0	125.0	11.4	15.0	32.94	99434	473816
111	111.2	111.1	120.7	20.6	25.4	41.91	99437	473817
111.79	111.99	111.9	120.7	19.1	22.5	33.02	99438	473818
112.62	112.83	112.7	122.2	25.4	29.0	33.35	99439	473819
114.2	114.4	114.3	124.5	20.6	25.4	31.75	99450	473820
114.88	115.09	115.0	127.0	20.6	23.8	31.75	99452	325847
117.37	117.58	117.5	127.0	11.1	15.9	34.93	99465	473822
117.37	117.58	117.5	128.6	25.4	31.8	34.93	99463	473821
119	119.2	119.1	128.6	20.6	25.4	34.93	99468	473823
119.89	120.09	120.0	129.8	8.0	11.0	33.6	99471	473824
119.89	120.09	120.0	129.8	20.0	25.0	32	99473	327396
120.55	120.75	120.7	127.0	12.7	19.1	38.1	99475	408162
121.89	122.1	122.0	131.5	20.0	24.0	32	99472	473825
122.91	123.11	123.0	132.8	20.0	25.0	31.6	99484	473826
123.72	123.93	123.8	133.3	15.9	19.1	36.53	99487	473827
124.89	125.1	125.0	137.2	10.0	14.0	36.53	99490	473828
124.89	125.1	125.0	137.2	26.0	32.0	36.53	99492	473829
124.89	125.1	127.0	136.9	20.6	25.4	36.53	99499	473831
126.95	127.15	127.0	137.2	13.7	17.3	36.53	99501	473832
126.95	127.15	127.0	137.2	17.5	22.2	36.53	99498	473830
129.79	130	129.9	139.5	19.1	23.8	30	99494	473833
129.97	130.18	130.2	139.5	22.0	25.3	32.51	99491	473834
130.05	130.25	130.2	139.7	20.6	25.4	31.75	99513	473835
133.25	133.45	133.4	141.2	20.6	25.4	31.75	99525	473836
134.8	135	135.0	145.7	20.5	25.4	31.75	99533	473837
136.42	136.63	136.5	149.2	20.6	25.4	31.75	99537	473838
138.02	138.23	138.1	146.1	38.1	49.9	47.63	99548	473839
138.99	139.19	139.1	149.9	14.3	19.1	31.34	99547	473840
139.65	139.85	139.7	150.8	13.2	17.9	31.75	99550	473842
139.65	139.85	139.7	150.8	20.6	25.4	31.75	99549	473841
139.9	140.11	140.0	151.0	20.5	25.4	31.75	99552	473843
142.77	142.98	142.9	157.2	22.2	25.4	46.02	99560	473844
144.75	145.01	145.0	154.9	19.1	22.2	46.02	99571	473845
145.44	145.64	145.6	154.9	14.3	19.1	49.23	99562	473846
145.95	146.15	146.1	157.0	20.6	25.4	44.45	99575	473847
149.12	149.33	149.2	157.2	25.4	31.8	33.35	99587	473848
149.76	150.01	150.0	159.0	26.0	30.0	32.51	99595	325848
150.72	150.93	150.8	161.9	25.4	28.6	47.63	99596	473849
152.27	152.48	152.4	161.5	12.7	19.1	44.45	99601	473851
152.27	152.48	152.4	161.9	25.4	31.8	44.45	99599	473850
153.87	154.13	154.0	161.9	26.0	30.0	32.99	99605	473852
154.74	154.99	154.9	167.0	26.0	30.0	32.99	99606	473853
157.43	157.68	157.6	168.3	20.6	27.0	44.45	99620	473854
158.62	158.88	158.8	168.3	26.2	31.8	44.45	99625	473855
159.74	159.99	160.0	171.4	25.4	31.8	34.93	99630	473856
164.97	165.23	165.1	177.8	25.4	31.8	34.93	99650	473857
169.75	170	169.9	182.6	31.8	38.0	44.45	99640	319638
171.32	171.58	171.5	181.0	20.6	27.0	44.45	99675	473858
174.75	175.01	175.0	187.0	28.0	32.0	35	99687	473859
177.67	177.93	177.8	189.9	25.4	31.8	42.88	99700	473860
179.76	180.01	180.0	190.5	33.0	38.0	44.5	99721	325854
184	184.25	184.2	197.1	31.8	38.1	55.25	99725	473861
184.73	184.99	184.9	197.1	32.0	38.0	54.99	99726	473862
189.08	189.33	189.3	199.6	20.6	25.4	31.75	99745	473863
190.37	190.63	190.5	200.0	20.6	25.4	31.75	99750	473864
196.72	196.98	196.9	210.1	25.4	33.4	47.63	99775	473865
199.87	200.13	200.0	212.7	34.5	38.1	44.45	99787	441178
201.5	201.75	201.6	212.7	25.4	31.8	44.45	99799	473866
203.07	203.33	203.2	212.7	25.4	31.8	44.45	99800	473867

PS-lips Gylon®

Garlock PS lips Gylon®

Some Information
