HUNGER seals
Hunger seals
Seal Supply can supply all standard HUNGER seals.
You can send your request to sales@sealsupply.nl.
Overview Hunger seals
| application Limits standard version | |||||
| category | profile | designation | pressure (bar) | temp. range (°C) | speed (m/s) |
| piston seal | GD1000K* | Slide Ring Seal (Piston) | 450 | -45 .. +120 | 1 |
| piston seal | GKD* | Compact Slide Ring Seal | 450 | -35 .. +100 | 1 |
| piston seal | GD2000P | Slide Ring Seal for Plunger | 450 | -30 .. +80 | 1 |
| piston seal | TDA* | Tandem Seal, outside sealing | 450 | -35 .. +100 | 1 |
| piston seal | TDMA* | Tandem Seal for Multi-Fluid Application, outside sealing | 250 | -35 .. +100 | 1 |
| piston seal | GGDA* | Captive Slide and O-Ring Seal, outside sealing | 450 | -35 .. +100 | 1 |
| piston seal | ZSDA* | Seal for Cylinders With Radial Drillings, outside sealing | 450 | -35 .. +100 | 1 |
| piston seal | GODA | Slide and O-Ring Seal, outside sealing | 360 | -35 .. +100 | 1 |
| piston seal | GDSA | Slide and O-Ring Seal, heavy-duty series, outside sealing | 360 | -35 .. +100 | 1 |
| piston seal | GODA-SP | Slide and O-Ring Seal, Step Profile, outside sealing | 360 | -35 .. +100 | 1 |
| rod seal | TDI* | Tandem Seal inside seaing | 450 | -35 .. +100 | 1 |
| rod seal | EVD | Externally Adjustable Sealing System | 300 | 0 .. +80 | 1 |
| rod seal | TDT* | Tandem Seal for Telescopic Cylinder | 360 | -35 .. +100 | 1 |
| rod seal | NDT | Lip Seal for Telescopic Cylinder | 250 | -35 .. +100 | 1 |
| rod seal | TDMI* | Tandem Seal for Multi Fluid Application, inside sealing | 250 | -35 .. +100 | 1 |
| rod seal | GGDI* | Captive Slide and O-Ring Seal, inside sealing | 450 | -35 .. +100 | 1 |
| rod seal | GGDI-SP | Captive Slide and O-Ring Seal, Step Profile, inside sealing | 450 | -35 .. +100 | 1 |
| rod seal | ZSDI* | Seal for Cylinders With Radial Drillings, outside sealing | 450 | -35 .. +100 | 1 |
| rod seal | GODI | Slide and O-Ring Seal, inside sealing | 360 | -35 .. +100 | 1 |
| rod seal | GDSI | Slide and O-Ring Seal, heavy-duty series, inside sealing | 360 | -35 .. +100 | 1 |
| rod seal | GODI-SP | Slide and O-Ring Seal, Step Profile, inside sealing | 360 | -35 .. +100 | 1 |
| wiper | AI | Wiper Ring, inside wiping (material, Hytrel) | - | -35 .. +100 | 1 |
| wiper | AI-D | Double Wiper, inside wiping | - | -35 .. +100 | 1 |
| wiper | AIST | Wiper Ring, Step Profile | - | -35 .. +100 | 1 |
| wiper | A-EIS | Ice Wiper | - | -35 .. +100 | 1 |
| wiper | A-EIS-S | Ice Wiper, Heavy duty series | - | -35 .. +100 | 1 |
| bearing | FI* | Bearing Ring, inside bearing | - | -55 .. +120 | 3 |
| bearing | FAI* | Bearing Ring with Wiping Function inside bearing | - | -55 .. +120 | 3 |
| bearing | FA* | Bearing Ring, outside bearing | - | -55 .. +120 | 3 |
| bearing | RFI | Square Bearing Ring, inside bearing | - | -55 .. +120 | 3 |
| bearing | RFA | Square Bearing Ring, outside bearing | - | -55 .. +120 | 3 |
| bearing | PFB | PTFE Bearing Strip | - | -200 .. +200 | 3 |
