HUNGER® Piston seals
Seal Supply also supplies piston seals of the HUNGER® brand from Germany. These are mostly special designs for heavy duty applications.
Read more
HUNGER® piston seals
Seal Supply also supplies hydraulic seals of the Hunger brand from Germany. These are mostly special designs for heavy duty applications. In the overview below, we have listed with an asterisk symbol (*) what the standard types from Hunger are, where it is more likely that the size you are looking for is in stock at Hunger or with us.
We look forward to receiving your enquiry at sales@sealsupply.nl.
Hunger piston seals overview
application limits standard version | |||||
category | profile | designation | pressure (bar) | temp. range (°C) | speed (m/s) |
piston seal | GD1000K* | Slide Ring Seal (Piston) | 450 | -45 .. +120 | 1 |
piston seal | GKD* | Compact Slide Ring Seal | 450 | -35 .. +100 | 1 |
piston seal | GD2000P | Slide Ring Seal for Plunger | 450 | -30 .. +80 | 1 |
piston seal | TDA* | Tandem Seal, outside sealing | 450 | -35 .. +100 | 1 |
piston seal | TDMA* | Tandem Seal for Multi-Fluid Application, outside sealing | 250 | -35 .. +100 | 1 |
piston seal | GGDA* | Captive Slide and O-Ring Seal, outside sealing | 450 | -35 .. +100 | 1 |
piston seal | ZSDA* | Seal for Cylinders With Radial Drillings, outside sealing | 450 | -35 .. +100 | 1 |
piston seal | GODA | Slide and O-Ring Seal, outside sealing | 360 | -35 .. +100 | 1 |
piston seal | GDSA | Slide and O-Ring Seal, heavy-duty series, outside sealing | 360 | -35 .. +100 | 1 |
piston seal | GODA-SP | Slide and O-Ring Seal, Step Profile, outside sealing | 360 | -35 .. +100 | 1 |
